Mechanical characteristics:
■ The upper wall, lower wall and center are driven by independent motors, with stable acceleration and deceleration; High rigid body structure and fixed column will not produce jitter during heavy pressure processing, making processing faster and more stable;
■ The precision pressure control system with force feedback is adopted, and the processing pressure is corrected in real time;
■ Equipped with high-precision online measurement system, the product processing thickness error can be controlled within 1um;
■ The center wheel height is 70mm, the lifting stroke of the gear ring is 100mm, and the 50mm thick grinding wheel can be installed;
■ When the gear ring and center wheel are made of stainless steel for polishing, they will not rust and affect the polishing;
■ It adopts an intuitive and good user control interface, which can flexibly set processing parameters and store 100 groups of processing parameters;
■ With powerful fault diagnosis function, it can help users quickly eliminate equipment faults;
